3
Introducing the 3L Small Form Factor
Onboard LAN
• Integrated Intel Gigabit Ethernet Controller for PCI Express TM Applications
• Integrated 10/100/1000 transceiver
• Wake-on-LAN and remote wake-up support
The motherboard comes with the following expansion options:
• Two SCN slots (MINI PCI Express slots)
• One SATA_HDD1 connector
• One SATA_ODD1 connector
• One TV1 header
Expansion Options
1394a FireWire (optional)
• Compliant with single chip host controller for IEEE Std 1394-1995 and
IEEE 1394a-2000
• Integrated 400 Mb/s 2-Port PHY for the PCI BUS
• 3.3V Power supply with 5V Tolerant Inputs
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
1. Some hardware specifications and software items are subject to change
without prior notice.
2. Due to chipset limitation, we recommend that motherboard be oper-
ated in the ambiance between 0 and 50
° C .
The firmware can also be used to set parameters for different processor clock
speeds.
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
• One J4 port (DC Jack)
• One VGA port
• One HDMI port
• Four USB ports
• One ESATA port
• One LAN port
• One optical SPDIFO port
• Audio jacks for microphone, line-in and 8-ch High Definition Audio
output
