1
Introducing the 3L Small Form Factor
Introducing the 3L Small Form Factor
Thank you for choosing 3L Small Form Factor of great performance and with stylish
and flexible design.
With Intel ® Core TM 2 Duo/Celeron ® processors inside and a dimension of 270mm
(H)* 200mm (D)* 60mm (W) (3 Liter), 3L Small Form Factor provides the features
of low power consumption (working with a 65Watt power adaptor), low noise (<28dB)
and space saving. It
incorporates the G43 Northbridge (NB) and ICH10 Southbridge
(SB) chipsets, supporting up to 4 GB of system memory with DDR2 memory SODIMM
frequencies of 800/667
MHz, 3.5 ” SATA II HDD, Slim DVD Supermulti Slot-in type
ODD, and Built in Intel ® GMA X4500 Graphics.
3L Small Form Factor is equipped with four USB 2.0 ports, two audio ports, one
1394a port (optional) in the front panel and advanced full set of I/O ports in the rear
panel, including J4, one VGA port, one HDMI port, four USB ports, one ESATA port,
one LAN port, one optical SPDIFO port, and audio jacks for microphone, line-in and
8-ch line-out.
Chapter 1
Introducing the 3L Small Form Factor
