Installing the Motherboard
1394A1: IEEE 1394a connector (optional)
It can be used to connect any device with IEEE 1394a interface.
JMIC1: Front Audio Microphone Jack
JPHOME1: Front Audio Line-out Jack
5
Pin Signal Name Pin Signal Name
2 LINE2_L
LINE2_R 4 LINE2_JD
N/C GND 6
1
3
GND
5
Pin Signal Name Pin Signal Name
GND 2 MIC2_L
MIC2_R 4 MIC2_JD
N/C GND 6
1
3
SPI_ROM1: SPI ROM header
This 8 Mb ROM contains the programmable BIOS program.
1 CHIP SELECT Select chip
2 VCC VCC
3 DATA OUTPUT data output
4 HOLD hold
5 WRITE PROTECT BIOS write protect
6 CLOCK clock
7 CND CND
8 DATA INPUT data input
Pin Signal Name Function
J3: SATA HDD power connector
Pin Signal Name Function 1 TPB-
2 TPB+
3 TPA-
4 TPA+
Pin Signal
Pin Signal Name Function
1 12V 12V power
2 GND Ground
3 VCC3 J3 power
4 5V 5V power
