19
Installing the Motherboard
COM1: Onboard serial port header
Connect a serial port extension bracket to this header to add a second serial port to
your system.
TV1: External S-VIDEO Header (optional)
4 RTSB RART B Request to Send
1 DCDB Data Carrier Detect
2 DSRB Data Set Ready
3 SINB Serial Input
5 SOUTB UART B Serial Output
6 CTSB Clear to Send
7 DTRB
8 RI Ring Indicator
9 Key No pin
10 GND Ground
Pin Signal Name Function
UART B Data Terminal Ready
FUSB1~4: Front Panel USB Ports
The motherboard has four USB ports installed on the rear edge I/O port array.
Additionally, some computer cases have USB ports at the front of the case. If you
have this kind of case, use auxiliary USB connector to connect the front-mounted
ports to the motherboard.
Please make sure that the USB cable has the same pin assignment as
indicated above. A different pin assignment may cause damage or
system hang-up.
1
3
data+
5
Pin Signal Name Pin Signal Name
VCC 2 data-
4 gnd
data-
vcc 6
7 8 data+ gnd
4 GND
1 S_VIDEO_Y
2 S_VIDEO_C
3 AUDIO_R_IN
5 AUDIO_L_IN
6 AV_IN
7 GND
8 GND
9 Key
10 GND
Pin Signal Name
