37
Using BIOS
This motherboard supports the latest PECI host technology. While using
Core
TM 2 Duo or Celeron TM CPU, the original images of the BIOS item “PC
Health Status” and “Smart FAN Function” will be replaced by PECI
mode and negative number. (The max data from PECI is -1.)
SMART Fan start PWM value 60
SMART Fan start Offset (-) 30
CPU DeltaT +3
Fan1 Slope PWM value/1 Unit 4
Press to return to the PC Health Status page.
mnlk : Move F10: Save ESC: Exit Enter: Select +/-/: Value
F9: Load default settings F1: General Help
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status
f
mnlk : Move F10: Save ESC: Exit Enter: Select +/-/: Value
F9: Load default settings F1: General Help
-=- System Hardware Monitor-=-
Smart Fan Function
Press Enter
Smart Fan Enabled
System Temperature : 36°C/96°F
SYS_FAN1 Speed : 2020 RPM
SYS_FAN2 Speed : 2170 RPM
CPU VCore : 1.200 V
VDIMM : 1.845 V
-=- PECI Mode-=-
Offset to TCC Activation Temp.: -51
SMART Fan start TEMP. (°C) (55)
This item is used to set the start temperature of the smart fan.
CPU DeltaT (+3)
This item specifies the range that controls CPU temperature and keeps it from going
so high or so low when smart fan works.
SMART Fan Slope PWM value (4 PWM value/°C)
This item is used to set the Slope Select PWM of the smart fan.
Press to return to the PC Health Status page.
