Page 51: Chapter 4, Chapter

Brocade Mobility 1240 Access Point Installation Guide
47
53-1002917-01
Chapter
4
Specifications
Electrical characteristics
A Mobility 1240 has the following electrical characteristics:
Physical characteristics
A Mobility 1240 has the following physical characteristics:
Operating Current &
Voltage
48VDC, 0.625A (AUX input voltage)
48VDC, 0.75A (PWRS-14000-247R power supply)
Dimensions
9 inches x 6.00 inches x 1.75 inches
22.9 cm x 15.2 cm x 4.4 cm
Housing
Metal
Weight (without facade)
3.2 lbs / 1.45 kg
Operating Temperature
32°F to 122°F/0°C to 50°C
Storage Temperature
-40°F to 185°F/-40°C to 85°C
Operating Humidity
5 to 95% Relative Humidity non-condensing
Storage Humidity
85% Relative Humidity non-condensing
Operating Altitude
(max)
8,000 ft @ 28C
Storage Altitude
(max)
30,000 ft @ 12C
Electrostatic Discharge
+/-15kV Air and +/-8kV Contact @ 50% Relative Humidity
