GEO T C
LUSTER
M
ECHANICAL
W
INDOW
Configuration Settings
Rigging Mode
NEXO GEO T
- Bumper Only (Tension Mode)
- Bumper + Half Kelping Beam (Tension mode), which allows greater distance between rigging
points
- Compression Mode + 20° Kelping Beam
- Compression Mode + Half Kelping Beam
Wind Beaufort 8
Corresponds to a 20.7 m/s wind. Options are:
- No Wind
- Wind from the back of the cluster
- Wind from the front of the cluster
Lateral wind is considered to have no influence on investigated forces.
Cluster Secured
It is assumed that wind cannot rotate cluster, and that therefore cluster does not need to be secured
