NXES104 EXPANSION BOARD, REMOTE CONTROL AND ASIO DRIVER
WARNING! Do not use FTP cabling for live application.
STP stands for Shielded Twisted Pair: Screen is made of copper braid. SFTP stands for
Overall Braid + Foil Shielded Twisted Pair: Foil screen and braid shield. For all these cables,
transmission characteristics are the same. The difference is the behavior with respect to
electromagnetic interference. We recommend cabling that has a superior quality sleeve in
order to protect the cable. Ideally this sleeve should halogen free in order to comply for the
installation standards.
Bellow are cables seriously
for information).
Manufacturer Cable
Reference
TYPE Max. length
without Error
Max length
for reliability
Specific comments on tested cables
786OE
FTP
130 m
110 m
Ruggedized Cat6 Cable, Shielded, AWG24
difficult to fit in standard RJ45 "male" plugs
(Blue)
1875GB
UTP
120 m
100 m
Flat smooth ruggedized Cat6 Cable, no
shield (White)
AudioLan
FTP
85 m
75 m
Really smooth ruggedized cat5e, Look like a
mic Cable, a little bit hard to mount on RJ45
at the beginning (Black)
AX CA23653
S-FTP 140m
120 m
Ruggedized Cat5e cable, really good for
exteriors, SFTP+One shield fold per pair
(Green)
Giga-Audio S-FTP
140m
120
m Ruggedized Cat5e cable, very good live
cable, SFTP+One shield fold per pair (Black)
799090
S-FTP 140 m
120 m
Really Ruggedized Cat5e cable, Does not fit
in standard RJ45 "male" plugs (0.22m
2
),
SFTP+One fold per pair (Black)
CT2672600
FTP
100 m
90 m
Ruggedized Cat5e cable (Black)
IP20 System
cables 4-pole
S-TP 100 m
100 m
Industrial Ethernet stranded cable.
RC5 RAMCATS
100 ohms
S-TP 70 m
65 m
STP stranded AWG26
RC5 SU
U/UTP 100 m
90 m
AWG24/1
Eurocable
Extraflex Cat5 UTP
85 m
75 m
Very smooth Ruggedized Cat5, Without any
shield so be careful with EMC problem
(Black)
Eurocable
Extraflex Cat5
S-FTP 123 m
105 m
Ruggedized Cat5 cable, very good live cable
(Black)
ZNK
CT2672601
S/FTP 90 m
80 m
Cat5E Cable, Shielded
PCCAT5EP
-
97 m
85 m
Cat5E Cable, Shielded
PCCAT5EPUTPP UTP
88 m
80 m
Cat5E Cable, No shield
