BEFORE FIRST TIME USE
Pour one-half bottle (4 ounces) of the RTI FUEL SYSTEM CLEANER
into the Fill Port.
Then pour gasoline into the Fill Port until the level is at the EMPTY
mark in the Fuel Level Window.
This will ensure precise concentration of fuel to cleaner.
Table of Contents
Component Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Keypad Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fuel System Identification . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Port Fuel Injection (PFI) Setup . . . . . . . . . . . . . . . . . . . . . . . 7
Port Fuel Injection (PFI) Cleaning Procedure . . . . . . . . . . . 10
Throttle Body Injection (TBI) Setup . . . . . . . . . . . . . . . . . . 11
Throttle Body Injection (TBI) Cleaning Procedure . . . . . . . 14
Continuous Injection System (CIS) Setup . . . . . . . . . . . . . 15
Continuous Injection System (CIS) Cleaning Procedure . . 18
Carburetor System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Carburetor System Cleaning Procedure . . . . . . . . . . . . . . . 22
Vehicle Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Intake System Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Parts Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Flow & Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
