<4. Maintenance>
4-1
IM 11M12D01-51E
4. Maintenance
Various sensor data can be viewed on the HART Communicator.
For more details, refer to “Section 10.1 Display” in the AV550G Instruction Manual.
Call up “
Channels” display.
1. Device setup ---> 4. Detailed setup ---> 2. Channels
Table 4.1 Meaning of Data Labels in “Sensors”
1
2
F030901-1.ai
STU
1
AV550G:
Channels
1 Ch1 detailed setup
2 Ch2 detailed setup
3 Ch3 detailed setup
4 Ch4 detailed setup
5 Ch5 detailed setup
HOME SAVE
AV550G:
Ch1 detailed setup
1 Ch1 status
2 Sensors
3 Error
4 Alarm
HOME SAVE
3 AV550G:
Sensors
1 Cell mV -0.02 mV
2 Cell temp 748 degC
3 CJ temp 0 degC
4 TC volt 31.17 mV
5 CJ val 996.6 ohm
HOME SAVE HELP
VWX
2
Select “ ” (this
example shows how to display
various data from Channel1).
Select “ ”
Various data from Channel 1 is
displayed. Meanings of data
labels in “ ” displayed on the
HART communicator are shown in
the table below.
Operation Display
Ch1 detailed setup
Senors
Senors
HART Communicator
display
Meaning of data
Cell mV
Cell temp
CJ temp
TC volt
CJ val
Heater duty Cell emf displayed
Cell temperature is displayed
Cold junction (reference junction) temperature is displayed
Thermocouple emf is displayed
Cold junction (reference junction) resistance is displayed
Heater duty cycle ON time is displayed
