<3. Parameters>
3-16
IM 11M12D01-51E
3.5 Blow Back
Here we explain how to excute a Semi-Auto Blow Back using HART communications.
This requires the AV550G Blow back mode to have been set to Semi-Auto or Auto.
For further details, refer to “Section 10.5 Blow Back” in the AV550G Instruction Manual.
Blow-Back-related parameters can not be set remotely using HART communication.
Blow Back can not be canceled using HART communication.
Call up “ Blow back” display.
1. Device setup ---> 2. Diag/Service ---> 4. Blow back
NOTE
1
2
(OK)
F030501-1.ai
F4
AV550G:
ABORT ON
Do you want to
execute blow back?
AV550G:
Diag/Service
1 Loop test
2 Calibration
3 Indication check
4 Blow back
5 Calib log
HELP SAVE HOME
Confirm that you want to execute
Blow Back
Blow Back is started using parameters
(Blow Back Time, Hold Time) set in
the AV550G
Display Operation
