Wa t l o w S e r i e s N 7
■
2 3
■
A p p e n d i x
Ordering Information and Model Numbers
Customer Name
Inputs 1 & 2
1 Input 1 & Input 2 thermocouple
2 Input 1 thermocouple, Input 2 process
3 Input 1 thermocouple, Input 2 RTD
4 Input 1 & Input 2 process
5 Input 1 RTD, Input 2 process
6 Input 1 & Input 2 RTD
Inputs 3 & 4
0 none
1 Input 3 & Input 4 thermocouple
2 Input 3 process, Input 4 thermocouple
3 Input 3 RTD, Input 4 thermocouple
4 Input 3 & Input 4 process
5 Input 3 RTD, Input 4 process
6 Input 3 & Input 4 RTD
Note: The thermocouple options for Inputs 3 and 4 need thermocouple population for Input 1.
Process Outputs 1 & 2, Event Inputs 5 to 8, Control Outputs 3 & 4
0 none
1 3 & 4 switched dc control outputs, event inputs
2 1 current output, 3 & 4 switched dc control outputs, event inputs
3 1 & 2 current outputs, 3 & 4 switched dc control outputs, event inputs
4 1 current output, 2 volts output, 3 & 4 switched dc control outputs, event inputs
5 1 volts output, 3 & 4 switched dc control outputs, event inputs
6 1 & 2 volts outputs, 3 & 4 switched dc control outputs, event inputs
7 1 volts output, 2 current output, event inputs
Ethernet Add-on Module
0 none
1 Ethernet
High-voltage Add-on Module
0 none
1 2 solid-state relays
2 4 mechanical relays and 2 solid-state relays
3 6 solid-state relays
4 2 mechanical relays; 4 solid-state relays
5 4 no-arc relays*; 2 solid-state relays
Horizontal or Vertical Display
1 vertical
2 horizontal left
3 horizontal right
Software and Customer Options
N 7 _ _ _ _ _ _ _ _ - _ _ _ _ _ _ _ _ - _ _ _ _ _ _ _ _
