Version 1.1 / November 98 Page 41
rlminstl.mnl
Diagnostics
Troubleshooting Mechanical Versions
RLM/M Diagnostics
PROBLEM RECOMMENDATION
RLM does not talk to tank monitor. Run Tester or WinTester utility.
RLM does not talk to Tester or Check jumper settings on RLM. Refer to Diagram:
WinTester. See "Testing the RLM" RLM (Electronic) Connector/ Jumper Layout
section. Baud correct?
Parity correct?
Stop bits correct?
Data bits correct?
Device address correct?
Check power indicator on RLM main board.
Check PC.
Comm port on PC OK?
RS232 cable plugged into PC?
Port parameters set correctly on Tester/ WinTester?
RLM does not capture any data. Make sure return switch is wired (operating)
correctly.
Make sure wiring for pulser and return switches is
correct.
