Progressive International Electronics RLM
Version 1.1 / November 98 Page 19
rlminstl.mnl
Table: Gilbarco DBoxes
Gilbarco dispensing systems use several types of distribution boxes. This table of DBox part
numbers with descriptions will assist you in determining which connection method to the RLM
meets your requirements. Gilbarco uses two different electrical means of transmitting data —
current loop and RS422. It is very important to determine this prior to installing the RLM.
DBox Part # Description
PA01330000 Old style DBox with circular DINN connector (current loop)
PA0261x000010 Universal DBox with DB9P male (current loop) — one board
1
PA0261x000020 Universal DBox with DB9P male (current loop) — two boards
1
PA0261x000011 Universal DBox with DB9S female (RS422) — one board
1
PA0261x000021 Universal DBox with DB9S female (RS422) — two boards
1
PA03060020 G-SITE DBox with RJ45 connector (current loop)
PA0242 TS1000 DBox with DB9P connector (current loop)
2
1 The Gilbarco Universal DBox may be configured as a one or two board unit, depending on the
fuel site dispensing equipment layout. If two boards and two inputs are used, multiple RLMs
are required. Please refer to Gilbarco document number MDE-2713 for detailed information
on this product.
2 Please refer to Gilbarco document number MDE-2381A or MDE-2382A for detailed information
on this product.
