System Installation
Pump Specific Installation
RLM-T for Tokheim Electronic Dispenser
Note all warnings at the beginning of installation section.
1. Plug the adapter cable (supplied by PIE) for Tokheim dispensers
into the adapter port on the RLM-T.
2. Determine the type of electrical communications used by the
Tokheim system. Match the RLM-T with the Tokheim system by
using the appropriate adapter board selection in the RLM-T.
Reference Diagram: RLM Tokheim Adapter Board later in this
section.
Two types of electrical communications techniques are used by
Tokheim — standard and RS422. The M98 and M94 Power
Centers all use Tokheim standard. The 67 DBox uses standard,
but may be modified in the field to run RS422. The 67B uses
RS422, but may be modified in the field to run standard.
Because of the ability to modify in the field, the model number
on the 67 and 67B may not accurately reflect the
communications method of the DBox settings. Contact the
Tokheim service company responsible for site service to confirm
DBox settings.
3. Locate the round black connectors on the existing console to
DBox cable. Disconnect the existing console/controller cable
from the Tokheim M98/M94 Power Center, the 67 DBox, or the
67B DBox. Attach the RLM adapter cable to the cable ends from
the console/controller and from the DBox/power center. Refer to
the next page for a diagram of a typical installation.
