2. Go to A:\ drive. Insert the Tester diskette and type Tester. This
loads the Tester program.
3. Determine the communication settings in the RLM from the
jumper settings (i.e., baud rate=9600, data bits=8, stop bits=1,
parity=N, RTS=+, device address=00).
4. Follow the prompts on the screen, setting Tester's parameters to
match those of the RLM.
5. The screen will fill with eight fueling positions with pump totals
information. If data appears scrambled on the screen, press E
to exit and recheck to make sure ANSI.SYS is loaded. These
totals represent the transactions the RLM has captured since it
was last reset.
Press T to view the next 8 positions, 9 through 16.
Press ? at any time to view a menu of the Tester commands.
To test the RLM serial comm port with Tester, follow 1-5
above and #6 below.
6. RLMs shipped from PIE will have all totals cleared. To test load
an RLM and to ensure the communications link between the
Tester program and the RLM, press L and look at "pump2 hose2"
position on the screen. It should read "1234567890". To reset
the RLM and clear all data, press R. All totals cells will show
zeroes. Check to make sure that the status message at the top of
each pump display reads "OK". See note at end of this section.
Testing the RLM with the "WinTester" Utility
