Table: RLM (Electronic) Jumper Settings
Jumper headers J1-J12 are used to configure the RLM.
Configuration is determined by the following settings.
Note: J1 - J12. 0 is no jumper. 1 is jumpered.
BAUD RATE
J1 J2 BAUD
0 0 9600
1 0 4800
0 1 2400
1 1 1200
DATA BITS
J3 Data Bits
0 7
1 8
STOP BITS
J4 Stop Bits
0 1
1 2
PARITY
J5 Parity J6 Parity
0 no 0 odd
1 yes 1 even
DEVICE ADDRESS
J9 (LSB) through J12 (MSB)
