14
11. Pull rod from air cylinder as far as possible. Slide washer #25 over set-
screw #20 and against nut attached to air cylinder rod. Place setscrew
into hole of shifter shaft #12 and attach air cylinder to gear box cover
using (4) capscrews #22. Apply Loc-tite PST thread sealer to threads of
capscrews. Torque capscrews to 5 ft-lbs. each, in crisscross pattern.
12
21
27
25
39
33
37
30
22
