SPRAY HEAD COMPONENTS Page 2
Spray Heads for A-BU- Automatic Spray Guns are available in several different Styles, some of which are available with Stainless
Steel components. The C.F.M. requirements range from 2 to 14 C.F.M. @ 30 to 40 lbs. air pressure. NOTE: When either fluid
Tip or fluid Needle is worn and requires replacement, it is recommended that both items be changed for best results. All Tips
and Needles are made using 303 Stainless Steel. Carbide Tips and Needles are available for use with abrasive materials.
• EXTERNAL- FAN PATTERN
• Sizes: 2 or 4
• Application: Application in tight areas - fast color change.
• Fluid Viscosity: Light to Medium (2 to 6 C.F.M. @ 30 P.S.I.)
1. BNFA- Fan Aircap (Select Size)
2. BU-12 Aircap Nut
3. U- Stainless Tip (Select Size)
4. A-U-4 Stainless Needle
• INTERNAL- ROUND PATTERN
• Sizes: 2 or 4
• Application: Fine lines, detailing stenciling and touch-up.
Latex, silver nitrate, acidic materials.
• Fluid Viscosity: Light to medium (2 to 3.5 C.F.M. @ 40 P.S.I.)
1. BR-15- Aircap Body (Select Size)
2. BU-12 Aircap Nut
3. U- Stainless Tip (Select Size)
4. A-U-4 Stainless Needle
• STAINLESS- INTERNAL- ROUND PATTERN
• Sizes: 2 or 4
• Application: Fine lines, detailing stenciling and touch-up.
Latex, silver nitrate, acidic materials.
• Fluid Viscosity: Light to medium (2 to 3.5 C.F.M. @ 40 P.S.I.)
1. BSR-15- Stainless Aircap Body
2. BUS-12 Stainless Aircap Nut
3. U- Stainless Tip (Select Size)
4. A-U-3-1/32 Stainless Needle
• STAINLESS- EXTERNAL- FAN PATTERN
• Sizes: 0 only
• Application: Corrosive materials.
• Fluid Viscosity: Light to Medium (3 to 5 C.F.M. @ 40 P.S.I.)
1. BSF-15- Stainless St. Fan Aircap (Select Size)
2. BUS-12 Stainless St. Aircap Nut
3. U- Stainless Tip (Select Size)
4. A-U-4 Stainless Needle
