AVL-3000 Advanced Auto Data Server

Page 77

6.2.14 SATA Drive Connector (SATA1)

6.2.15 SPI Flash Connector (SPI1)

6.2.16 USB 2.0 Connector (USB5)

PIN NO.

DESCRIPTION

1 GND

2 SATA_TXP

3 SATA_TXN

4 GND

5 SATA_RXN

6 SATA_RXP

7 GND

Table 6-15: SATA Drive Connector (SATA1) Pinouts

PIN NO.

DESCRIPTION

1 VCC3

2 CS

3 MISO

4 CLK

5 MOSI

6 GND

Table 6-16:

SPI Flash Connector (SPI1) Pinouts

PIN NO.

DESCRIPTION

1 VCC5

2 DATA-

3 DATA+

4 GND

Table 6-17: USB 2.0 Connector (USB5) Pinouts
