AVL-3000 Advanced Auto Data Server
Page 71
6.2.5 OBD-II Connector (OBDII1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 NC 2 J1850-
3 NC 4 J1850+
5 OBD-CAN_H 6 ISO-9141-2-L
7 ISO-9141-2-K 8 NC
9 OBD-CAN_L 10 NC
6.2.6 PCI-104 Slot, Only PCIe Interface (PCI1)
Pin Description Pin Description Pin Description Pin Description
A1 +V12S B1 +V12S C1 +V12S D1 +V12S
A2 NC B2 NC C2 NC D2 NC
A3 +V5S B3 +V5S C3 +V5S D3 +V5S
A4 +V5S B4 +V5S C4 +V5S D4 +V5S
A5 NC B5 NC C5 NC D5 NC
A6 +V3.3S B6 +V3.3S C6 +V3.3S D6 +V3.3S
A7 +V3.3S B7 +V3.3S C7 +V3.3S D7 +V3.3S
A8 NC B8 NC C8 NC D8 NC
A9 GND B9 GND C9 GND D9 GND
A10 PCIE_TXP B10 GND C10 GND D10 GND
A11 PCIE_TXN B11 GND C11 GND D11 GND
A12 PCIE_RXP B12 GND C12 GND D12 GND
A13 PCIE_RXN B13 GND C13 GND D13 GND
A14 CLK_PCIE_CLK_P B14 GND C14 GND D14 SMB_DATA
A15 CLK_PCIE_CLK_N B15 WAKE# C15 PCIRST# D15 SMB_CLK
Table 6-7: PCI-104 Slot (PCI1) Pinouts
Table 6-6: OBD-II Connector (OBDII1) Pinouts
