Connector Type Label
PCIe Mini card slots 52-pin PCIe Mini slot MINI_PCIE1,
MINI_PCIE2,
MINI_PCIE3
Power button and LED connector 4-pin wafer PW_BTN1
Programmer connectors 5-pin header JOBD1, MCU1
RS-232 serial port connectors 10-pin header,
40-pin header
COM1, COM6,
JCOM7
Serial ATA (SATA) drive connector 7-pin SATA SATA1
SPI flash connector 6-pin wafer SPI1
USB 2.0 connector 4-pin wafer USB5
Table 6-1: Peripheral Interface Connectors
6.2.1 5 V SATA Power Connector (SATA_PWR1)
6.2.2 Battery Connector (BT1)
PIN NO. DESCRIPTION
1 VCC5
2 GND
Table 6-2: 5 V SATA Power Connector Pinouts
PIN NO. DESCRIPTION
1 VBATT
2 GND
Table 6-3: Battery Connector (BT1) Pinouts
