AVL-3000 Advanced Auto Data Server
Page 45
IO=2F8h;
IRQ=10
Serial Port I/O port address is 2F8h and the interrupt
address is IRQ10
IO=250h;
IRQ=10
Serial Port I/O port address is 250h and the interrupt
address is IRQ10
4.3.6 F81866 H/W Monitor
The F81866 H/W Monitor menu (BIOS Menu 9) displays the CPU and system
temperatures.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature : +56 C
System Temperature : +54 C
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 9: F81866 H/W Monitor
PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
CPU Temperature
System Temperature
