UP C-V315-NM70 P a n e l P C
P a g e 78
4.4.2.2 NB P CIe Co n fig u ra tio n
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PEG0
Not Present
PEG0 – Gen X [Auto]
Configure PEG0 B0:D1:F0
Gen1-Gen3
----------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 19: NB PCIe Configuration
 PEG0 – Gen X [Au to ]
Use the PEG0 – Gen X option to select the support type of the PCI Express (PEG)
controller. The following options are available:
 Auto Default
 Gen1
 Gen2
 Gen3
