UP C-V315-NM70 P a n e l P C
P a g e 65

IO=2E0h;
IRQ=5, 7
Serial Port I/O port address is 2E0h and the interrupt
address is IRQ5, 7

IO=2E8h;
IRQ=5, 7
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ5, 7
4.3.7 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+50 C
Accuracy: 1.(-5~+10)degree around 100 degree
2.(-10~+15)degree around 50 degree
System Temperature
:+41 C
V_CORE :+0.808 V
V_5S :+5.129 V
V_12S :+11.968 V
V_1.5V :+1.600 V
VSB5V :+5.136 V
VCC3V :+3.344 V
VSB3V :+3.360 V
VBAT :+3.296 V
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save
ESC Exit
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 Temperatures:
o CPU Temperature
o System Temperature
 Voltages:
o V_CORE
