Page 20: N 1.4.5)

UP C-V315-NM70 P a n e l P C

P a g e 9

1.4.5 Fra m e (Fu n c tio n Ke ys )

An aluminum frame surrounds the TFT LCD screen. The aluminum frame of the

UPC-V315-NM70 contains several function keys that control audio volume, LCD

brightness and some other system components.

Figure 1-8: Function Key Locations

The following table describes the function of these function keys.

Buttons

Function

Buttons

Function

Function

LCD on/off

Enable/Disable RFID

Audio volume down

Mute audio

Audio volume up

Enable/Disable

webcam

Brightness up

Enable/Disable

3G USB 2.0 port

Brightness down

Power on/off

(Turn on: press 3 seconds

Turn off: press 6 seconds)

Table 1-2: Function Keys
