UP C-V315-NM70 P a n e l P C

P a g e 12

Audio

AMP 3W + 3W (Internal Speaker)

Camera

2M Mega Pixels

Connectivity

Wireless

IEEE 802.11a/b/g/n 3T3R module (WIFI-RT5393-DB-R10)

Bluetooth

Bluetooth V2.0+EDR with USB interface (optional)

3G

Reserved USB connector (Optional)

Drive Bay

HDD Driver Bay

1 x 2.5” SATA SSD

SSD

mSATA

CD-ROM Driver Bay

N/A

System Cooling

Fanless

Physical

Construction Material

Aluminium alloy

Mounting

VESA 100mm x100mm or 75mm x 75mm with M8 screws

Front Panel Color

Orange (Paintone 15C)

Dimension (WxHxD) (mm)

427.19 x 330.63 x 71.6

Net Weight

7.97KG

Environment

Operation Temperature

-20°C ~60°C

Storage Temperature

-30°C ~70°C

Operating Humidity

5% ~90%, non-condensing

Shock

Half-sine wave shock 3G; 11ms; 3 shocks per axis

Vibration

MIL-STD-810F 514.5C-1 (with CF card or SSD)

IP Rating

Full IP 65
