KINO-9453 Mini-ITX Motherboard
Page 31
4.1.2 Peripheral Interface Connectors
Table 4-1 shows a list of the peripheral interface connectors on the KINO-9453. Detailed
descriptions of these connectors can be found in Section 4.2.
Connector Type Label
ATX power supply connector 20-pin ATX connector PWR1
Digital I/O connector 10-pin header DIO1
Fan connector (CPU) 3-pin wafer CPU_FAN1
Fan connector (Northbridge) 3-pin wafer NB_FAN1
Fan connector (System) 3-pin wafer SYS_FAN1
Front panel connector 14-pin header F_PANEL1
IDE Interface connector 40-pin box header IDE1
LVDS connector 30-pin crimp LVDS1
LCD backlight connector 6-pin wafer connector CN1
PCI slot 124-pin slot PCI2
Mini PCI Card slot 124-pin slot MINIPCI
Serial ATA (SATA) connector 7-pin SATA connector SATA1
Serial ATA (SATA) connector 7-pin SATA connector SATA2
Serial port connector (COM 3) 14-pin header COM3
Serial port connector (COM 4) 10-pin header COM4
SPDIF connector 5-pin header SPDIF1
USB connector 8-pin header USB4
USB connector 8-pin header USB5
Table 4-1: Peripheral Interface Connectors
