KINO-9453 Mini-ITX Motherboard
Page 23
2.9.2 Operating Temperature and Temperature Control
The maximum and minimum operating temperatures for the KINO-9453 are listed below.
Minimum Operating Temperature: 0ºC (32°F)
Maximum Operating Temperature: 60°C (140°F)
A cooling fan and heat sink must be installed on the CPU. Thermal paste must be
smeared on the lower side of the heat sink before it is mounted on the CPU. Heat sinks
are also mounted on the Northbridge and Southbridge chipsets to ensure the operating
temperature of these chips remain low.
2.9.3 Power Consumption
Table 2-4 shows the power consumption parameters for the KINO-9453 running with a
2.33 GHz Intel
®
Core™2 Duo T7600 processor with 2 GB of DDR2 memory.
Voltage Current
+5V 4.1A
+12V 2.23A
5VSB 0.58A
Table 2-4: Power Consumption
Table 2-4 shows the power consumption parameters for the KINO-9453 running with a
2.33 GHz Intel ® Core™ Duo T2700 processor with 2 GB of DDR2 memory.
Voltage Current
+5V 4.16A
+12V 1.96A
5VSB 0.59A
Table 2-5: Power Consumption
