IEI Integration KINO-9453 v2.00 - Manual (Page 181)

KINO-9453 Mini-ITX Motherboard
Page 163
7.6 Realtek HD Audio Driver (ALC883) Installation
To install the Realtek High Definition (HD) Audio driver, please follow the steps below.
7.6.1 BIOS Setup
Step 1: Enter the BIOS setup. To do this, reboot the system and press D EL during POST.
Step 2: Go to the Southbridge Configuration menu. Set the Audio Controller option to
[Azalia]. See Chapter 6 for details.
Step 3: Press F10 to save the changes and exit the BIOS setup. The system reboots.
Step 0:
7.6.2 Driver Installation
Step 1: Insert the CD that came with the package.
Step 2: From the main driver menu, navigate to X:\4-AUDIO\AC-KIT883HD\Windows
(or other appropriate OS). X:\ represents the system CD drive. A new window
appears showing the folder contents (Figure 6-26).
Figure 7-22: 4-AUDIO\AC-KIT883HD\Windows Folder
Step 3: Double-click the WDM_R140 icon to begin the driver installation process.
