ICE-PV-N4551_D5251 COM Express Type 2 Module
Page 58
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
WinBond W83627EHG HardWare Monitor
CPU Fan Speed
:N/A
Fan 2 Speed :N/A
+12V :+10.824 V
AVCC :+0.160 V
3VCC :+0.160 V
+3.3V :+3.200 V
VSB :+0.144 V
VBAT :+0.144 V
Set Fan Duty Cycle
CPU Fan Setting 255
Fan 2 Setting 255
Set Fan at fixed
Duty-Cycle Min=0 Max=255
Please input Dec number:
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: F75387 HardWare Monitor
 CPU Fan Setting
Use the + or – key to change the CPU Fan Setting value. Enter a decimal number
between 0 and 255.
 Fan 2 Setting
Use the + or – key to change the Fan 2 Setting value. Enter a decimal number between 0
and 255.
