ICE-PV-N4551_D5251 COM Express Type 2 Module
Page 34
4.4 Jumper Settings
NOTE:
A jumper is a metal bridge used to close an
electrical circuit. It consists of two or three
metal pins and a small metal clip (often
protected by a plastic cover) that slides over
the pins to connect them. To CLOSE/SHORT
a jumper means connecting the pins of the
jumper with the plastic clip and to OPEN a
jumper means removing the plastic clip from a
jumper.
Jumper Locations
Before the ICE-PV-N4551/D5251 is installed in the system, the jumpers must be set in
accordance with the desired configuration. The jumpers on the ICE-PV-N4551/D5251 are
listed in
3
Table 4-1 and shown in Figure 4–2.
Description Type Label
LVDS panel resolution 4-in-1 switch SW1
Table 4-1: Jumpers
Figure 4–2: Jumper Locations
