ICE-PV-N4551_D5251 COM Express Type 2 Module
Page 20
Pin No. Description Pin No. Description
C33 PCI_C/BE1# D33 PCI_SERR#
C34 PCI_PERR# D34 PCI_STOP#
C35 PCI_LOCK# D35 PCI_TRDY#
C36 PCI_DEVSEL# D36 PCI_FRAME#
C37 PCI_IRDY# D37 PCI_AD16
C38 PCI_C/BE2# D38 PCI_AD18
C39 PCI_AD17 D39 PCI_AD20
C40 PCI_AD19 D40 PCI_AD22
C41 GND D41 GND
C42 PCI_AD21 D42 PCI_AD24
C43 PCI_AD23 D43 PCI_AD26
C44 PCI_C/BE3# D44 PCI_AD28
C45 PCI_AD25 D45 PCI_AD30
C46 PCI_AD27 D46 PCI_IRQC#
C47 PCI_AD29 D47 PCI_IRQD#
C48 PCI_AD31 D48 PCI_CLKRUN#
C49 PCI_IRQA# D49 PCI_M66EN
C50 PCI_IRQB# D50 PCI_CLK
C51 GND D51 GND
C52 PEG_RX0+ D52 PEG_TX0+
C53 PEG_RX0- D53 PEG_TX0-
C54 TYPE0# D54 PEG_LANE_RV#
C55 PEG_RX1+ D55 PEG_TX1+
C56 PEG_RX1- D56 PEG_TX1-
C57 TYPE1# D57 TYPE2#
C58 PEG_RX2+ D58 PEG_TX2+
C59 PEG_RX2- D59 PEG_TX2-
C60 GND D60 GND
C61 PEG_RX3+ D61 PEG_TX3+
C62 PEG_RX3- D62 PEG_TX3-
C63 RSVD D63 RSVD
C64 RSVD D64 RSVD
