ICE-PV-N4551_D5251 COM Express Type 2 Module
Page 53
5.3.7 Super IO Configuration
Use the Super IO Configuration menu (
3
BIOS Menu 9) contains the submenus for
changing the FDD controllers, parallel ports and serial ports.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Super IO Configuration
Super IO Chip
Winbond W83627EHG
> Floppy Disk Controller Configuration
> COM 1 Configuration
> COM 2 Configuration
> Parallel Port Configuration
Set Parameters of Floppy
Disk Controller (FDC)
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 9: Chipset
5.3.7.1 Floppy Disk Controller Configuration
 Floppy Disk Controller [Enabled]
Use the Floppy Disk Controller option to enable or disable the floppy disk drive.

Disabled Disables the floppy disk controller.

Enabled D EFAULT Enables the floppy disk controller.
 Change Settings [Auto]
Use the Change Settings option to set the serial port IO and interrupt addresses.

Auto D EFAULT Disables the floppy disk controller.

IO=3F0h;
IRQ=6;
DMA=2
Serial Port I/O port address is 3F0h, the interrupt
address is IRQ6, and the DMA is 2.
