ICE-PV-N4551_D5251 COM Express Type 2 Module
Page 38
5.1 Introduction
NOTE:
The BIOS items shown below are from an ICE-PV-N4551/D5251
installed on the ICE-DB-9S-R10 reference carrier board. The
ICE-DB-9S-R10 reference carrier board is available from iEi, contact
or go to
for more
information.
The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to
certain system settings. This chapter outlines the options that can be changed.
5.1.1 Starting Setup
The UEFI BIOS is activated when the computer is turned on. The setup program can be
activated in one of two ways.
1. Press
the
F2
key as soon as the system is turned on or
2. Press
the
F2
key when the “Press F2 to enter SETUP” message appears on
the screen.
0.
If the message disappears before the F2 key is pressed, restart the computer and try
again.
5.1.2 Using Setup
Use the arrow keys to highlight items, press E
NTER
to select, use the PageUp and
PageDown keys to change entries, press F1 for help and press E
SC
to quit. Navigation
keys are shown in.
Key
Function
Up arrow
Move to the item above
Down arrow
Move to the item below
Left arrow
Move to the item on the left hand side
