AHCI Configures SATA devices as AHCI device.
5.3.4 USB Configuration
Use the USB Configuration menu (
3
BIOS Menu 6) to read USB configuration information
and configure the USB settings.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
USB Configuration
USB Devices:
1 Keyboard
USB Function
[Enabled]
USB 2.0(EHCI) Support [Enabled]
Legacy USB Support [Enabled]
Enable / Disable USB
Function.
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 6: USB Configuration
 USB Devices
The USB Devices Enabled field lists the USB devices that are enabled on the system
 USB Function [Enabled]
Use the USB Function BIOS option to enable or disable USB function support.

Disabled USB function support disabled

Enabled D EFAULT USB function support enabled
 USB 2.0(EHCI) Support [Enabled]
Use the USB 2.0(EHCI) Support BIOS option to enable or disable USB 2.0 (EHCI)
support.
