Fully Automatic AED Plus Administrator’s Guide 41
ECG Analysis Algorithm Accuracy
Sensitivity and specificity are expressions of ECG analysis algorithm performance when compared to
ECG interpretation by a clinician or expert. Sensitivity refers to the algorithm’s ability to correctly
identify shockable rhythms (as a percentage of the total number of shockable rhythms); specificity
refers to the algorithm’s ability to correctly identify non-shockable rhythms (as a percentage of the
total number of non-shockable rhythms). The data in Table 11 and Table 12 summarizes the accuracy
of the ECG analysis algorithm as tested against ZOLL’s ECG Rhythm Database.
The algorithm sequence takes approximately 9 seconds and proceeds as follows:
• Divides the ECG rhythm into three-second segments.
• Filters and measures noise, artifact, and baseline wander.
• Measures baseline content (“waviness” at the correct frequencies — frequency domain analysis)
of signal.
• Measures QRS rate, width, and variability.
• Measures amplitude and temporal regularity (“auto-correlation”) of peaks and troughs.
• Determines if multiple 3 second segments are shockable then prompts the user to treat patient.
• Stops analyzing the ECG after detecting a shockable rhythm and the AED Plus unit is charged
and automatically delivers a shock.
Table 11: Clinical Performance Results (Adult Patients)
Rhythms Sample
Size Performance
Goals Observed
Performance 90% One-sided
Lower
Confidence
Limit
Shockable (250 Total min.) 618
Coarse VF
Rapid VT
535
83
>90% sensitivity
>75% sensitivity
97.38%
91.57%
95.65%
83.39%
Non-shockable (300 Total min.) 3039
NSR
AF, SB, SVT, Heart block,
idioventricular, PVCs
Asystole
2205
770
64
>99% specificity
>95% specificity
>95% specificity
99.86%
100%
100%
99.60%
99.52%
99.40%
Intermediate
Fine VF
Other VT
88
64
24
Report only
Report only
93.75% sensitivity
91.67% sensitivity
84.76%
73.00%
