Fully Automatic AED Plus Administrator’s Guide
3
Operation
This section describes the following functions:
• Operating Controls and Indicators
• Using the Fully Automatic AED Plus Graphical User Interface
• Voice Prompts
• Using the LCD Display
• Using the Passive Airway Support System (PASS)
• Using Electrodes
• Applying CPR-D-padz
• Applying pedi-padz II (Infant/Child Electrodes)
• Using the CPR Monitoring Function — Real CPR Help
• Using the Audio Recording Option
Operating Controls and Indicators
See Table 1: Control Functions for an explanation of each of these controls.
Figure 1: Identifying Operating Controls and Indicators
Automatic
LCD Display (not supplied on
some units)
Graphics
Indicator Lights
Electrode Connector
Status
Indicator
Carrying Handle
IrDA Port (on side of unit)
Shock Indicator
Speaker (bottom)
Battery Compartment (bottom)
On/Off Button
