P/N 11440-001 Rev. 3 Page A-5
User Guide
A.8 Battery Charger Physical
A.9 Battery Charger Environmental
Table A-7 Battery Charger Physical Specifications
Category Specifications
Size (L×W×H) 15 in. by 9.75 in. by 9.1 in. (38 cm by 25 cm by 23 cm).
Weight 10 lbs. (4.5 kg)
Operating input voltage 100 to 240V AC
Operating input frequency 50/60 Hz
Input current 2.0 Amps (maximum)
Maximum Battery charge
time Less than 4
1
/
4
hours (at 77ºF [25ºC])
Fuses User-replaceable, T2.0A 250V AC (2 required)
Table A-8 Battery Charger Environmental Specifications
Category Specifications
Operating temperature +41º to +95ºF (5º to +35ºC) (68º to 77ºF [20º to 25ºC] preferred)
Storage temperature -40º to +158ºF (-40º to +70ºC)
Relative humidity 5% to 95%, non-condensing.
Operating altitude 0 to 10,000 ft. (0 to 3,048 m)
Enclosure protection Meets IP22 per IEC 60529
Shock (non-operational) Meets IEC 60068-2-27 Basic Environmental Testing Procedures – Shock (50g,
11ms pulse, half sine wave)
Vibration (non-operational) Meets IEC 60068-2-6 Basic Environmental Testing Procedures 10 to 150 Hz, 10
m/s
2
Meets IEC 60068-2-64 Basic Environmental Testing Procedures – Random
Vibration Broad Band – General Requirements (f1:20, f2:2000, ASD 0.05)
Free fall (non-operational) Meets IEC 60068-2-32 Basic Environmental Testing Procedures – Free Fall –
Procedure 1.
Safety requirements Safety certified to UL2601, CSA 22.2 No. 601.1-M90, EN60601-1
