4. AutoPulse Li-Ion batteries placed in a charging bay are automatically charged and tested for
minimal performance (Charging LED illuminated) in less than 4
¼ hours.
5. AutoPulse NiMH batteries placed in a charging bay are automatically charged and tested for
minimal performance (Charging LED illuminated) in less than 6
¼ hours.
Note: Do not remove a Battery from the Multi-Chemistry Battery Charger until its charging
completes, or the Battery’s run time will be reduced.
6. The AutoPulse Multi-Chemistry Battery Charger automatically conducts a Performance Test on
both the AutoPulse Li-Ion Battery and the AutoPulse NIMH Battery to ensure each Battery meets
performance standards. The Performance Test occurs every time a Battery is placed into the
AutoPulse Multi-Chemistry Battery Charger.
7. Once the green LED on the Charger illuminates the Battery is fully charged and has successfully passed
the Performance Test. The Battery is ready to use.
Table 4-1 AutoPulse Multi-Chemistry Battery Charger Status LEDs (Page 1 of 2)
Multi-
Chemistry
Battery
Charger
Mode
Multi-Chemistry
Battery Charger
Status LEDs Used
Definition Action
Charge Charging (yellow LED) The Battery is charging. Leave the Battery in the Charger until
the Ready (green) LED illuminates.
Test-Cycle Charging (yellow LED)
Test (amber LED)
Typical Test-Cycles last up to 12
hours. Leave the Battery in the Charger until
the Test-Cycle completes and the
ready (green) LED illuminates.
Ready Ready (green LED) The Battery is fully charged and
has successfully passed the
Performance Test. The Battery
is ready to use. • Leave the Battery in the Charger
to ensure that the Battery is fully
charged when needed or
• Install in the AutoPulse Platform
or
• Store in a cool location.
Fail Fail (red LED) • The Charger was unable to
charge the Battery or
• the Battery has failed the
Performance Test or
• the Battery has failed a test
cycle or
• the Battery has reached its
end of life.
Remove and re-insert the Battery into
the Charger. If the Fail LED remains
illuminated, contact ZOLL.
