12 Warner Electric • 800-825-9050 P-209 • 819-0517
PB-1225 Brake–Heavy Duty
Shaft Size .750 – 2.687
Static Torque 465 lb. ft.
Maximum Speed 3,000 rpm
Standard Voltage D.C. 6, 24, 90
Customer Shall Maintain:
1. Squareness of magnet mounting face with
armature shaft within .006 T.I.R.
2. Concentricity of magnet mounting pilot
diameter with armature shaft within .010 T.I.R.
Armature View
* Mounting holes are within .010 of true position relative to pilot diameter.
Magnet View
5/16-18
UNC-3A
.562
1.640
.562
7.531
.921
1.546
.062
.234
4.093
Dia.
12.671
Max.
Dia.
2.500
2.687
4.167 Max.
See page 20 for details
on Bushings.
.358/.338 dia.
(8) holes equally
spaced on
13.000 dia.
6.378/6.376 Pilot
Dia.
3.750
13.875/12.871
Pilot Dia.
.358/.338 dia. (6) holes
equally spaced on 7.250
dia.
Removable plug in ends for
1/2" conduit.
8.687 Max.
