5 Warner Electric • 800-825-9050 P-231 • 819-0382
Dimensions
2.79
(70.81)
OPTIONAL CONDUIT BOX
5200-101-010
3.75 (95.25) NOM
ø.192
(4.88)
MIN.
4.69
(119.13)
MAX.
R2.312
(58.72)
NOM.
45°
ø.4.290 (108.97) MAX.
+.010
-.000
C
+.002
-.000
A
+.002
-.000
B
3X 1/4-20 UNC-2B
.270 (6.86) MAX FULL THD
EQUALLY SPACED
ON ø3.500(88.9)
.25
(6.35)
R1.563
(39.67)
.50
(12.69)
33°
ø.200 MAX. (5.08)
24°
ш.635 (16.12)
ш2.645 MAX. (67.13)
1.75
(44.42)
1.64
(41.62)
.17
(4.31)
ø1.498 ± .001
(38.02 ± .025)
.80
(20.30)
COLLAR REQUIRED
ON .500 AND .625
BORES ONLY
.47
(11.93)
.06
(1.52)
+.010
-.000
C
+.002
-.000
A
+.002
-.000
B
2x #10-32UNF-2B
SET SCREWS
3x #10-32UNF-2B
ш
ш2.000
(50.76)
ш1.20
(30.48)
MIN.
.955
(25.26)
NOM.
.060
(1.52)
NOM.
.014
(.35)
MIN.
1.55
(39.37)
NOM.
1.00
(25.4)
NOM.
.525
(13.3)
MAX.
2X. 1/4-20
SET SCREW
2.998 ± .001
(76.15 ± .025)
.180
(45.72)
NOM.
3.070 (77.98) MAX.
SFP-250
SFP-400
Dimensions
Model A Keyway Part Number
No. Bore B C 6V 24V 90V
.375" .094 .421 5103-271-002 5103-271-006 5103-271-010
SFP-250
.438" .126 .479 5103-271-003 5103-271-007 5103-271-011
.500" .126 .560 5103-271-004 5103-271-008 5103-271-012
.6255" .1885 .678 5103-271-005 5103-271-009 5103-271-013
.5005" .125 .560 5104-271-006 5104-271 -016 5104-271-021
.6255" .187 .709 5104-271-007 5104-271 -017 5104-271-022
SFP-400 .7505"
.187 .837 5104-271-008 5104-271-018 5104-271-023
.8755" .187 .964 5104-271-009 5104-271-019 5104-271-024
1.0005" .187 1.090 5104-271-010 5104-271-020 5104-271-025
