Warner Electric PTB-BL3 - Manual (Page 2)

2 Warner Electric • 800-825-9050 819-0368
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation Instructions . . . . . . . . . . . . . . . . 3-6
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . 7
Overhung Load Data . . . . . . . . . . . . . . . . . . . 8
Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Mechanical Data . . . . . . . . . . . . . . . . . . . . . . 10
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 11-16
Warranty . . . . . . . . . . . . . . . . . . . . . . Back Page
Introduction
This service manual provides information
required for installing, wiring, and maintaining
Warner Electric Magnetic Particle clutches and
brakes. Dimensions and specifications are also
included. The models covered in this service
manual include POC and PHC-R clutches and
POB and PTB brakes. For selection information,
please refer to your Warner Electric Tension
Control Sytems Catalog.
Warner Electric Magnetic Particle clutches and
brakes provide smooth and controllable torque
for a variety of torque and tension control appli-
cations. They also provide excellent perform-
ance for cycling and positioning applications.
Quick response is achieved by applying full
rated voltage. Lower voltage can be applied for
softer engagements. Extremely accurate tension
control can be achieved with an appropriate
Warner Electric tension control for electric
brakes and clutches.
Failure to follow these
instructions may result in product damage,
equipment damage, and serious or fatal
injury to personnel.
Make sure all power is turned
off to this equipment when installing, as
injury (or even death) may result from contact
with live wires or rotating shafts.
