Dimensions – Warner Electric ERS Electrically Released Brakes User Manual
Page 4

4
Warner Electric • 800-825-9050
819-0337
Dimensions
*Available only on the ERS-49, 57, and 68 sizes.
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
Model
Max.
Max.
Dia.
Dia.
ERS-26
2.460
1.515
1.375
1.125
.860
1.250
–
–
–
–
–
2.125
.172/.164
4-40
.375
(63)
(39)
(35)
(28)
(22)
(32)
(54)
(4)
–
ERS-42
3.520
1.595
2.000
1.600
1.375
1.255
–
–
–
–
–
3.125
.200/.190
6-32
.400
(90)
(41)
(51)
(41)
(35)
(32)
(79)
(5)
–
ERS-49
4.270
1.767
2.600
1.750
1.500
1.332
3.625
4.625
1.000 1.625
3.750
3.750
.228/.218
8-32
.400
(109)
(45)
(66)
(44)
(38)
(34)
(92)
(117)
(25)
(41)
(95)
(95)
(6)
–
ERS-57
5.020
1.937
3.240
2.100
1.750
1.503
4.000
5.000
1.170 1.625
3.750
4.500
.288/.278
10-24 .400
(128)
(49)
(82)
(53)
(44)
(38)
(102)
(127)
(30)
(41)
(95)
(114)
(7)
–
ERS-68
6.520
2.030
4.504
2.800
2.425
1.565
4.750
5.750
1.265 1.625
3.750
5.875
.413/.404
1/4-20 .500
(166)
(52)
(114)
(71)
(62)
(40)
(121)
(146)
(32)
(41)
(95)
(149)
(10)
–
(–) denotes millimeters
Note: Mating holes for mounting brake to be within .014 diameter true position, max. material condition, to the center of shaft.
