Specifications – Warner Electric Electro-Brake 375, 475, 650, 825, 1000, 1225 User Manual
Page 14
14
Warner Electric • 800-825-9050
P-211 • 819-0043
Specifications
Inertia–WR
2
(lb. ft
2
)
Model Size
Voltage DC
Static Torque lb. ft.
Max. Speed RPM
Arm. & Hub
Hub
Total Weight lbs.
EB-1000
6, 24, 90
240
2000
.720
.129
35.5
EB-1225
6, 24, 90
465
2000
1.8
.129
52.5
EB-1000, EB-1225
Adapter Requirements
For thru-shaft mounting, specify bore size. Order
bushing separately.
For motor mounting order adapter separate (see
page 4).
Size
A Max.
B Max.
C Dia.
D
E
F
G
H
I
J Max.
K
L
M
1000
10.328
6.344
2.563
1.563
1.500
7.688
6.531
1.281
1.547
3.531
2.266
4.531
–
1225
12.672
6.969
3.391
.875
1.750
8.438
7.531
1.297
1.547
3.719
2.453
4.703
–
Size
N
O
P Max.
Q
R
S
T
U
V
W
X
Y
Z
1000
–
–
7.688
3.750
–
18.000
1.500
.750
.2375
3.375
1.438
.413
–
.404
1225
–
–
8.688
3.750
–
18.000
1.500
.750
2.375
3.375
1.438
.413
–
.404
Removable
Plug In Ends
for 1/2" Conduit
Q
P
R
T
S
U
V
W
Y
X
J
I
H
G
C
B
A
K
L
F
D
E
