Operating Procedures DMOM-200™
2
2.0 DMOM-200  SPECIFICATIONS
Table 1.0 DMOM-200  Specifications and Leading Particulars
MODEL .............................................DMOM-200  (part number VIC-9000-100)
TYPE..……… ..................................Special-purpose test equipment, portable; 100-ampere,
Digital Micro-Ohm Meter
POWER ............................................85 to 132 V ac or 200-240 V ac (selectable), 50/60 Hz
SIZE (inches) ....................................16.8 wide by 12.6 high by 10.6 deep
WEIGHT............................................Less than 21 lbs
TEST CURRENT ..............................10 to 200 amperes
RESISTANCE READING RANGE ...1 micro-ohm to 300 milliohms
ACCURACY ..................................... ±1% reading, ± 1 count
DISPLAY ..........................................LCD, 4-line by 20-character, back lighted
CONTROLS......................................Keypad: 10 number keys and 6 function keys
COMPUTER INTERFACE ................RS-232C
PRINTER ..........................................Thermal printer (prints on 2.5-inch-wide thermal paper)
ENVIRONMENT ...............................Operating: 0 °C to 55°C; Storage: -40°C to 65°C
FURNISHED .....................................One power cord, one 35-foot test cable set,
One cable bag
EXPENDABLES ...............................Paper, thermally sensitive, 2.5-inch wide roll
(VIC part # TP-3)
WARRANTY .....................................One-year warranty on parts and labor; post warranty
service contracts available
NOTE:
THE ABOVE SPECIFICATIONS ARE VALID AT NOMINAL OPERATING VOLTAGE AND AT A TEMPERATURE OF 25 ° C
(77 ° F)
DMOM-200  SPECIFICATIONS MAY BE UPGRADED AND CHANGED WITHOUT PRIOR NOTICE.
