Operating Procedures DMOM-200™
19
5.8 Print Test Record Directory Procedure
This procedure describes the steps to print
the test record directory that is stored in the
DMOM-200
 Flash EEPROM.
Table 8.0 Print Test Record Directory
STEP ACTION DMOM-200  DISPLAY
8-1 On the RESTORE RECORD display (step 7-
2), press key #2 (DIRECTORY) to go to a
print menu of print options.
8-2 PRINT DIRECTORY choice is to print either
a FULL DIRECTORY or a SHORT
DIRECTORY. Regardless of which choice is
selected, the PRINTING DIRECTORY notice
displays as the selected directory prints out a
paper copy. When printout is completed,
display returns to the START MENU. This
ends the directory procedures.
NOTE
The Short directory printout lists the
last 10 test records stored in Flash
EEPROM memory.
Figure 7.0 Typical Directory Printout
PRINT DIRECTORY
1. FULL DIRECTORY
2. SHORT DIRECTORY
PRINTING DIRECTORY
