4 IQ3xcite Web Enabled Controller Installation Instructions TG200626 Issue 2 21/04/08
IQ3xcite Installation Instructions
Connect Output Power (P) 9
3 Installation - Mounting
(continued)
either use IQ3xcite 24 Vdc auxiliary supply
4 5 6 2 7 8 9 3 10 11 12 4 13 14 15 5 16 17 18 6 19 20 21 7 22 23 24 8 25 26 27 9 28 29 30 10 + 0 + 0 + 0 + 0 + 0 + 0 + 0 + 0 + 0
1 2 3 1 + 0
0 V 24 V 24 V 34 35 36
12
37 38 39
13
40 41 42 14 A 31 32 33 P
11
43 44 45
15
46 47 48
16 100-240 V OK RX P 0 P 0 P 0 P 0 P 0 P 0
A
0 V 24 V 24 V
A
31 32 33 P
11
P 0
A
PSU
0V 24
V
24
V
A
31 32 33 P
11
P 0
or use 24 Vdc or 24 Vac external supply
Fit external link
terminal size 0.5 to 2.5 mm 2 (14 to 20 AWG)
if P terminal used (see step 8 above)
Check IQ3xcite 24 Vdc
combined and auxiliary
output current availability:
IQ3 Configuration
Manual TE200768
External PSU with
isolated output
WARNING
External PSU must be dedicated
to I/O channel use, and comply
with relevant EMC and safety
standards
WARNING
If external supply is used, note whether P bus
is 24 Vac or 24 Vdc and only connect appropriate
output devices to P output terminals
EN61010:2001 MEASUREMENT CATEGORY 1
Separate from 230 Vac input power supply by double or
reinforced insulation
Connect external supply (no external link)
4 5 6 2 7 8 9 3 10 11 12 4 13 14 15 5 16 17 18 6 19 20 21 7 22 23 24 8 25 26 27 9 28 29 30 10 + 0 + 0 + 0 + 0 + 0 + 0 + 0 + 0 + 0
1 2 3 1 + 0
0 V 24 V 24 V 34 35 36 12 37 38 39 13 40 41 42 14 A 31 32 33 P 11 43 44 45 15 46 47 48 16 100-240 V OK RX P 0 P 0 P 0 P 0 P 0 P 0
A
0 V 24 V 24 V
A
P
IQ3
24 V
0 V
A
Connect Auxiliary Supply (24 V )
10
terminal size 0.5 to 2.5 mm 2 (14 to 20 AWG)
Imax = 150 mA(including current to P bus,
- see step 9 above)
if required
Check IQ3xcite 24 Vdc
combined and auxiliary
output current
availability:
IQ3 Configuration
Manual TE200768
Note that the 24 Vdc supply is normally about 22 V
and drops to about 20.7 V at full load.
EN61010:2001 MEASUREMENT CATEGORY 1
Separate from 230 Vac input supply by double or
reinforced insulation
Install I/O Modules 12
(IQ3XCITE/96/.. and /128.. only)
if required
XCITE Standard I/O Modules Installation Instructions TG200627
Installation, section 3 steps 1 to 11 only
Install Auxiliary Board 11
IQ3../.../LAN/... Installation Instructions TG200916 section 1
for IQ3../.../LAN/...
for IQ3../.../XNC/.., including
IQ3../.../LAN/XNC/..., IQ3../.../SER/XNC/...
IQ3../.../XNC/... Installation Instructions TG200911 section 1
if fitted (for battery board, BBC/UK, see section 4 step 9)
