XCITE/TERM Installation Instructions TG200645 Issue 1/B 22/05/06 1
Installation Instructions
XCITE/TERM
I/O Bus Terminator
Important: Retain these instructions
Manufactured for and on behalf of the Environmental and Combustion Controls Division of Honeywell Technologies Sàrl, Ecublens, Route
du Bois 37,Switzerland by its Authorized Representative, Trend Control Systems Limited.
Trend Control Systems Limited reserves the right to revise this publication from time to time and make changes to the content hereof
without obligation to notify any person of such revisions or changes.
Trend Control Systems Limited
P.O. Box 34, Horsham, West Sussex, RH12 2YF, UK. Tel:+44 (0)1403 21888 Fax:+44 (0)1403 241608 www.trend-controls.com
Trend Control Systems USA
6670 185th Avenue NE, Redmond, Washington 98052, USA. Tel: (425)869-8400, Fax: (425)869-8445 www.trend-controls.com
Installation
Install IQ3xcite and I/O Modules
1
(IQ3XCITE/96/... only)
IQ3xcite Installation Instructions,
TG200626
xcite Standard I/O Modules
Installation Instructions, TG200627
O
I
Switch Off 2
Open Flap 3 Plug in Terminator 4
on I/O module at furthest end of I/O bus
from main controller or on main
controller (if no I/O modules used)
XCITE/TERM
on I/O module at furthest end of I/O bus
from main controller or on main
controller (if no I/O modules used)
Close Flap
5 6
Switch On
O
I
a b
