ZS4000 High-Impedance, Active Probe
2 923360-00 Rev A
Operating Environment
The accessory is intended for indoor use and should be operated in a clean, dry
environment. Before using this product, ensure that its operating environment is
maintained within these parameters:
Temperature: 0 to 40° C.
Humidity: Maximum relative humidity 80 % for temperatures up to 31 °C
decreasing linearly to 50 % relative humidity at 40° C.
Altitude: Up to 10,000 ft (3,048 m).
Introduction
The ZS4000 is a small, high-impedance active probe designed to meet today’s
increasing demand for measurements on a variety of test points. With low input
capacitance and high input resistance, circuit loading is minimized.
The ZS4000 can be used with Teledyne LeCroy’s WaveSurfer, WaveRunner,
WavePro, and WaveMaster oscilloscopes with firmware version 7.1.1.2 or later.
With the ProBus interface, the probe becomes an integral part of the
oscilloscope, able to be controlled from the oscilloscope’s front panel. The
oscilloscope provides power to the probe, so there is no need for a separate
power supply or batteries.
See the product page at teledynelecroy.com for probe specifications.
Key Benefits Features

High frequency performance

Low input capacitance

Wide dynamic range

ProBus interface

Small, low mass probe head is
designed for ease of use and high
performance.

Probe tip socket fits easily onto 0.025
inch square pins for direct access to
test points. Several available
adaptors connect directly to the
probe socket.

Ground socket accepts several
different ground leads to provide a
short ground path for high frequency
performance.
